| Parameter | Specification |
|---|---|
| Conductor Materials | Silver Plated Copper or Bare Copper |
| Conductor Type | Stranded or Solid |
| Insulation | PTFE, FEP, or PFA |
| Number of Cores | Single Core or Multiple Cores |
| Size Range | 0.05~4mm² |
| Rated Voltage | 600V or Below |
| Temperature Range | -80°C to +200°C |
| Available Colors | White, Blue, Red, Black, Yellow, Green, Transparent, Yellow/Green |
| Type | Description |
|---|---|
| AFR-200 | Bare Copper wire conductor PTFE film insulated lead wire |
| AFR-250 | Silver plated copper wire conductor PTFE film insulated lead wire |
| AFP | Bare Copper wire conductor PTFE film insulated screen lead wire |
| AFP-1 | Silver plated copper wire conductor PTFE film insulated screen lead wire |
| AFRP-200 | Bare Copper wire conductor PTFE film insulation shield lead wire |
| AFRP-250 | Silver plated wire copper conductor PTFE film insulation shield lead wire |
| AFRPF-250, AFPF | Silver plated wire copper conductor PTFE film insulation PTFE film sheath shield lead wire |
| Wire Gauge | Cross-section | Conductor Structure | Max. OD (mm) | Reference Weight (kg/km) |
|---|---|---|---|---|
| 36AWG | 0.013 | 7/0.05 | 0.57 | 0.44 |
| 32AWG | 0.035 | 7/0.08 | 0.67 | 0.73 |
| - | 0.05 | 10/0.08 | 0.72 | 0.91 |
| - | 0.07 | 14/0.08 | 0.75 | 1.16 |
| - | 0.1 | 21/0.08 | 0.85 | 1.57 |
| 26AWG | 0.12 | 24/0.08 | 0.85 | 1.66 |
| - | 0.14/0.15 | 30/0.08 | 0.9 | 2.07 |
| 24AWG | 0.2 | 42/0.08 | 1.0 | 2.72 |
| - | 0.25 | 56/0.08 | 1.1 | 3.47 |
| 22AWG | 0.3 | 62/0.08 | 1.18 | 4.2 |
| - | 0.35 | 75/0.08 | 1.2 | 4.7 |
| 20AWG | 0.5 | 63/0.1 | 1.45 | 5.36 |
| - | 0.75/0.80 | 91/0.1 | 1.69 | 8.19 |
| 18AWG | 1 | 56/0.15 | 1.95 | 10.9 |
